Overview:
C*Core’s standard security TF card and the high-performance one are composite products designed based on C*Core’s security chips- CCM3302S and CCM3304S respectively. Both function as standard SD cards for storage and as SD-KEYs, for supporting various operating systems including Windows, Linux, and Android. They also support algorithms such as SM2/SM3/SM4/RSA1024/RSA2048,which can be widely used in PKI authentication, digital signatures, data (real-time) encryption and decryption, and secure data storage.
2.1. SD KEY
The SD KEY is a product that integrates USB KEY function into an SD card. The built-in security module provides various secure applications through the SD interface, such as certificate storage, digital signatures/authentication, access control, data (real-time) encryption and decryption, and secure data storage. It can cover all the functions of current U-shields. It extends the application area of USB KEY from PCs to handheld devices such as PDAs and mobile phones.
2.2. Security Storage
The Security TF Card provide a complete technical solution for security data storage applications, which can be customized according to customers’ requirements. The high-capacity, high-performance Security TF Card currently supports a maximum capacity of 128GB, SD2.0 protocol for high-speed storage applications. In addition, it supports national cryptographic algorithms for secuity storage. It can achieve the following functions:
(1) Data encryption
(2) Data hiding
3. Parameters
| Parameter | Security TF Card Specification | High-Capacity Security TF Card |
Processor | C*Core’s 32-bit RISC chip | C*Core’s 32-bit RISC chip |
Communication Protocol | SD2.0 standard protocol | SD2.0 standard protocol |
EFLASH | Available capacity 128KB | Available capacity 256KB |
Operating Temperature | Commercial grade: 0℃~70℃ | Industrial grade: -20℃~85℃ |
Operating Voltage | 3V | 3V |
Power Consumption | Operating current ＜ 60mA | Operating current ＜ 100mA |
Middleware | Supporting the "Smart Card and Smart Token Cryptography Application Interface Specification" issued by the State Cryptography Administration Supports the unique CSP interface to Windows | Supporting the "Smart Card and Smart Token Cryptography Application Interface Specification" issued by the State Cryptography Administration Supports the unique CSP interface to Windows |
Storage Capacity | 0GB/4GB/8GB/16GB | 0GB/32GB/64GB/128GB |
Storage Performance | Write > 5MB/S, Read > 15MB/S | Write > 10MB/S, Read > 18MB/S 64GB/128GB: Write > 18MB/S, Read > 18MB/S |
Algorithm | SM2/SM3/SM4/ RSA1024/RSA2048 | SM2/SM3/SM4/ DES/AES/RSA1024/RSA2048 |
4. Appearance
TF Card
5. Product Qualification
Level II of crypto module for commercial crypto product certification
? Surveillance
? Online banking
? File encryption
? Certificate Authority
? E-government affairs
? Copyright control
? Secure office
? Secure email
? Complete development environment
? Rich driver library
? Complete application solutions
